Solar	 Woodle
Specifications
Solar Woodle Module Specifications
Type: Part no:
SolarWoodle Module 6x6 SW_M6_ST
SolarWoodle Module 8x8 SW_M8_ST
SolarWoodle Module Round 8 in SW_MRD_ST
Frame Material
Stainless steel (StSt)
Stainless steel (StSt)
Stainless steel (StSt)
Solar Panel
Tempered Glass
Tempered Glass
Tempered Glass
Software Setting
Sunset ON - Sunrise OFF
Sunset ON - Sunrise OFF
Sunset ON - Sunrise OFF
Light Type
LED
LED
LED
Light Colour*
3000K
3000K
3000K
Light Intensity
150-200 Lumen
150-200 Lumens
150-200 Lumens
Average Charge Time**
6 Hours
3.5 Hours
6 Hours
Battery Type
LG 18650 (3600mA) Li-ion
LG 18650 (3600mA) Li-ion
LG 18650 (3600mA) Li-ion
Guaranteed Illumination Time
10 Hours
10 Hours
10 Hours
Warranty***
3 years
3 years
3 years
* Other Colours (Red / Amber / Blue / Green) on request ** Measured with full sunlight *** Conditions apply; Please refer to our ‘Warranty & limitation of Liability’ statement; Battery: 1 year We reserve the right to introduce changes in performance, configuration and technology, dimensions, weights and materials in the couse of technical progress. The figures and images are illustrative and shown without obligations. Prices may change due to wood market prices. Please check before ordering.
